Tlhaloso ea Lihlahisoa

4450 Winch Relay

450A AMPS DC Winch Motor Reversing Solenoid Relay 12 Volt Contactor

Contact Data

Tokisetso ea ho Kopana		2C(2PDT)
Boitsebiso ba ho Kopana		Alloy
Lintlha tsa Lebitso (tse hanyetsanang)		450A 12VDC
Max. Ho Fetola Matla		5400W
Max. Ho fetola Voltage		75VDC @80A
Ikopanye le Resistance		50m Ω Max
Motlakase o sebetsang	Motlakase	Lipotoloho tse 20,000 tse tsoelang pele ho 80A 12VDC, li-cycle tse 2,000 ka linako tse ling ho 450A 12VDC
	Mechini	100,000 lipotoloho

Parameter ea Coil

Lebitso

Motlakase (VDC)

Voltage e phahameng haholo (VDC)

Khanyetso ea Coil

Ω ± 10% ka likhato tse 20

Nka

Palo ea li-volts

(VDC ka likhato tse 20)

Lokolla

Voltage (VDC ka likhato tse 20)

Matla a Coil

(W)

14.4

4.2

9.0

0.6

Boemo ba Ts'ebetso

Khanyetso ea Insulation	100M Ω min (ho 500VDC)
Matla a Dielectric Pakeng tsa mabitso Pakeng tsa ho kopana le khoele	50Hz 1000VAC 50Hz 1000VAC
Ho hana ho tshoha	10G
Khanyetso ea ho thothomela	10 ~ 55Hz habeli amplitude 1.5mm
IP MOKHOA	IP67
Ambient Mocheso	-40-55 likhato
Mongobo o Batlang	93% (ka likhato tse 40)

product-800-1236

product-746-549

Boholo (mm)

Wiring

WINCH SOLENOID 500A ke karolo ea bohlokoa bakeng sa ho laola litsamaiso tsa li-winch, tse etselitsoeng ho netefatsa ts'ebetso e tšepahalang libakeng tse hlokang. Lintlha tsa eona tsa bohlokoa ke tsena:

Lintho tse bonahalang

Ntlo ea WINCH SOLENOID 500A e entsoe ka polasetiki e tšoarellang, e fana ka khanyetso e ntle ea mocheso le ho hanyetsa ho bola ho mamella maemo a thata a kantle. Litheminale li entsoe ka koporo ea boleng bo holimo -, e netefatsang hore motlakase o sebetsa hantle le ho tšoarella ha nako e telele -.

Mosebetsi

E sebetsa joalo ka sesebelisoa sa motlakase, se nolofalletsang taolo e nepahetseng ea matla a winch le tataiso. Ha e kenyelelitsoe tsamaisong ea winch, e nolofatsa ts'ebetso ea winch, joalo ka ho hula kapa ho lokolla liropo, 'me e netefatsa phetiso ea matla a thellang.

Libaka tsa Kopo

WINCH SOLENOID 500A e sebelisoa haholo ho li-winch system tsa likoloi (mohlala, bakeng sa - pholoso tseleng, ho khutlisa koloi), lisebelisoa tsa winch ea marine (mohlala, bakeng sa ho emisa sekepe, ho tsamaisa thepa), le lisebelisoa tsa liindasteri tsa winch (mohlala, bakeng sa ho phahamisa thepa, ho tsamaisa lintho tse boima {{8}). E boetse e loketse maemo a pholoso a tšohanyetso (mohlala, pholoso ea lefeelleng, thuso ea likoluoa) moo taolo e tšepahalang ea winch e leng bohlokoa.

Tlhaloso ena e khuts'oane e totobatsa ho tšoarella ha thepa ea relay, ts'epahalo ea ts'ebetso, le bophara bo pharaletseng ba ts'ebeliso libakeng tse amanang le win -.
